Notice: The picture shown is a sample temperature, it is for reference only, the actual product may vary.

reaPoint

professional
material plastic
measuring points 1
protected yes
dishwasher suitable yes
accuracy 1% above 100°C +/- 1°C below 100°C
reaction time 1-2 sek.
dimensions 17 x 17 mm
13x13 mm (on request)

storage conditions cool, dry
customization possible yes

Our REATEC reaPoint professional temperature indicators are based on a self-adhesive plastic carrier, that is protected by a high-quality PET film. The temperature measuring point is placed between these two layers and is protected.

Available
Product No. °C
037.PPP.01.XXX 37,8
040.PPP.01.XXX 40,6
043.PPP.01.XXX 43,3
046.PPP.01.XXX 46
049.PPP.01.XXX 49
054.PPP.01.XXX 54,4
060.PPP.01.XXX 60
065.PPP.01.XXX 65,5
071.PPP.01.XXX 71
075.PPP.01.XXX 75
077.PPP.01.XXX 77
082.PPP.01.XXX 82
088.PPP.01.XXX 88
093.PPP.01.XXX 93
099.PPP.01.XXX 99
104.PPP.01.XXX 104
110.PPP.01.XXX 110
116.PPP.01.XXX 116
121.PPP.01.XXX 121

Features

  • self-adhesive temperature measuring strips
  • permanent color change from grey to black
  • for use in the environment of water
  • for use in the environment of oils
  • for use in the environment of greases
  • for use in the environment of solvents
  • 1 measuring point per indicator
  • wide range of temperatures
  • also customizable
  • robust PET protective film

Beschreibung

Temperature measuring points in use:

Our temperature measuring points are supplied on sheets of 50 indicators. They are very easy to apply to the object to be measured and have very high adhesion even under strong external loads.

As soon as the specified temperature is exceeded, the temperature measuring point will change color within 1 to 2 seconds.

The color change is irreversible; once the temperature is exceeded, the temperature measuring points do not change back to the original color, even if the temperature drops again. Critical temperature fluctuations will be indicated.

Sonstiges

This indicator is characterized by its water and oil repellency, strength, high-density, high performance adhesive and the perfectly adapted material selection gives the fastest possible response time.

Temperatures 37,8°C - 43,3°C store in a refrigerator
